Vintage Inspired
Built upon the shoulders of giant RCA mics, each JRS-34 ribbon is cut, corrugated and installed by hand.
Modern Electronics
Custom CineMag transformers, a patented round magnet, and Cloudlifter JFET technology expand the JRS-34's performance for today's applications.
Made in the USA
Shipped in a custom wood case
with a two year ribbon warranty and a limited lifetime
warranty on all other parts.
Active Output
The active JRS-34 requires phantom power and has an output level compatible with virtually any modern preamp.
Specifications
Figure 8 polar pattern w/ -35db null at 90°
Patented Rounded Magnet technology
Phantom Powered “Cloudlifter” Class A, Discrete Circuity
Ribbon dimensions: .19" wide, 2.35" long, 1.8 microns thick
New mount offers 180 degree range of motion
Internally shock mounted
Handmade entirely in the USA
Dimensions: 7.75” x 3” x 1.75”
Weight: 1.03lbs
Frequency Response: 20 HZ – > 20kHz
Output Sensitivity: -27 dBv/Pa
Max SPL: 138 dB > 1kHz
Out Impedance (in Ohms): 150 ohms
Recommended Load (in Ohms): 1kohm or greater
Supplied Accessories: Wood Case, Mic cover
Optional Accessories: Cloud U1 Shockmount
Patents: 8,433,090; 9,167,327; 9,888,315;
10,356,507; 10,721,552; D605,637
*RCA is a registered trademark of Radio Corporation of America. References to RCA are historical in nature and imply no affiliation with Cloud Microphones.
Raise Your Voice
The Cloud JRS-34 combines the best attributes of vintage & modern ribbon
microphone technologies.
Designed in collaboration with Stephen Sank, the prefix JRS pays homage to the late Jon R. Sank, who was known for his work with RCA that produced legendary microphones.
